Horse Fencing

Since horses can get easily spooked, enclosures need to be more than just a barrier – they need to withstand the impact a horse can have when pushing against it and keep your animal safe and injury-free.

Inquire Now

Introduction

Our mesh fencing design provides the strength needed to withstand a horse's power, but also prevents your horse from getting its hoof stuck and injured.

Advantage

1.Smooth finish stuff stay type joints that prevent injury to horses and foals - no sharp edges to cut

2.Smaller apertures to prevent horses and foals from getting their legs and hooves through the mesh and injuring themselves

3.Selection of mesh heights to suit all applications - 900 to 1500mm wide rolls

4. 2.5mm hi-tensile heavy galvanised wires for long life and extra strength

5.These meshes are easy to install and fix to both steel and timber posts

Technical

Height	1070mm (42"), 1270mm (50")
Length	50m
Weight	56kg (42"), 66kg (50")
Line Wires	10 (42"), 11 (50")
Intermediate Line Wires	2.5mm - 1235-1390 n/mm²
Top/Bottom Line Wires	2.5mm - 1235-1390 n/mm²
Vertical Line Wires	2.5mm - 695-850 n/mm²

Main Functions

Key Feature

· Small openings

The openings in horse wire fences are small enough to prevent horses from getting their hooves caught.

· No sharp edges

Horse wire fences are designed to have no exposed sharp edges that could cut a horse's skin.

· Strong and durable

Horse wire fences are strong and durable, making them one of the safest fences for horses.

· Visible

Horse wire fences are visible to horses, especially when combined with a rail across the top.

Benefits

Compliance with Standards: The fencing meets BS EN 10223-5/10244-2, ensuring strength and durability for equestrian use.
Horse-Friendly Design: With a 3" (8cm) spacing between vertical wires, the fence prevents horses and ponies from injuring their hooves by getting them caught.
High Tensile Strength: High tensile fencing can be installed tighter and at higher tension than mild steel, making it stronger and more durable. It does not stretch, providing superior performance over time.
Fewer Posts Required: Due to its strength, high tensile fencing requires fewer intermediate posts, making installation quicker and more cost-effective compared to mild steel fences.

Purpose

The purpose of a horse wire fence is to safely contain horses while still allowing them to graze and exercise.

Application

This strong wire fencing system is designed mainly for equine uses, however it will also fit the requirements for other needs, such as:
1.Paddock safety
2.Boundary security
3.Livestock areas
4.Forest and land boundaries
The wire fence system is built to be durable and long-lasting in order to reduce the maintenance costs and risk of breakages in the fence line. Therefore, ensuring that your paddock perimeter is securely guarded at all times.
